RXF36 M.2 Coil 27.5 / Stroke 120 - 170 mm / Offset 38 mm
RXF36 M.2 Coil 27.5 / Stroke 120 - 170 mm / Offset 38 mm
Ohlins

Ohlins RXF36 M.2 Coil 27.5 / Stroke 120 - 170 mm / Offset 38 mm

€1,662.30
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

Ohlins RXF36 M.2 Coil 27.5 / Stroke 120 - 170 mm / Offset 38 mm

Season:2023

Brand:Ohlins

Code:RXF36 M.2 Coil 27.5 170

The race proven TTX18 dampening from the DH38 Race Fork has been reworked for the all new RXF36 M.2 fork to give optimal traction and control on trails and Enduro race courses. The RXF36 M.2 is available as an Air or Coil fork. The TTX18 cartridge kit featuring trail-optimized 18 mm piston for improved small bump sensitivity. With increased damping pressure bandwidth the damping valve response and sensitivity has improved.

The damping adjustment range is set specifically for trail to Enduro race use with 15 clicks of low speed compression and low speed rebound. For the high speed compression damping you get 3 clicks plus a climb mode setting. The retuned twin piston three chamber air spring system allows total air spring tuning from the initial movement through to the bottom out.

Technical Specifications:

  • Coil spring (different spring rates available as an option)
  • Weight approx. 2380 g (with full steerer and heaviest rate spring)
  • Stroke 120 - 170 mm (170 mm standard stroke, please see note below)
  • Stanchion tubes 36 mm
  • Axle 15 x 110 mm
  • Offset 38 mm
  • Wheel size 27,5
  • Maximum tire sizes 29 x 2,8 / 27,5 x 2,8 / 27,5+ x 3,2
  • Aluminium design, hard anodized
  • Fully servicable and rebuildable
  • 2 years limited warranty

Please note, that the RXF36 M.2 Coil forks are supplied with 170 mm travel as a standard. Please inform us about the stroke you want so we can change if needed. This change is free of charge.

Adjustment:

  • Spring preload
  • 15-click rebound damping
  • 15-click low speed compression damping
  • 3-click high speed compression damping
  • Climb mode
  • Optional springs available (see below)

Purchased parts package:

  • 1 MTB front fork RXF 36 M.2 Coil
  • 1 axle 15 x 110 mm
  • 1 star-nut
  • Owners manual
Technical Information

Technical Specifications:

  • Coil spring (different spring rates available as an option)
  • Weight approx. 2380 g (with full steerer and heaviest rate spring)
  • Stroke 120 - 170 mm (170 mm standard stroke, please see note below)
  • Stanchion tubes 36 mm
  • Axle 15 x 110 mm
  • Offset 38 mm
  • Wheel size 27,5
  • Maximum tire sizes 29 x 2,8 / 27,5 x 2,8 / 27,5+ x 3,2
  • Aluminium design, hard anodized
  • Fully servicable and rebuildable
  • 2 years limited warranty

Please note, that the RXF36 M.2 Coil forks are supplied with 170 mm travel as a standard. Please inform us about the stroke you want so we can change if needed. This change is free of charge.

Adjustment:

  • Spring preload
  • 15-click rebound damping
  • 15-click low speed compression damping
  • 3-click high speed compression damping
  • Climb mode
  • Optional springs available (see below)
